Description
[Ideal Air Conditioning Maintenance Tool]
The air conditioner pressure gauge adopts the most advanced digital circuitry and high-precision pressure sensor (Accuracy: 0.5%). Widely used automotive air conditioner, domestic air conditioner, refrigeration chamber and refrigeration plant. The real-time pressure test obtained the relative temperature which can help you to be more convenient for the installation or service of the refrigeration system.
[Three working modes]
The R410a pressure gauge set comes with three common working modes: coolant pressure mode, vacuum percentage mode, leak detection mode. Equipped with real-time vacuum pressure test and percentage indication. Test range: 0 KPa~6000 KPa. Operating temperature: -20C~60C (-4F-140F), but the L202 cannot measure microns.
[Built in 90 Refrigerants]
AC Diagnostic Pressure Gauge Set 90 built-in refrigerants and corresponding temperature sheet data in accordance with U.S. NIST standard.
[Powerful Function]
R134A A/C pressure gauge set equipped with automatic shutdown function, unit conversion and backlight function. By default, the system automatically shuts down after 10 minutes of inactivity. Users can configure by canceling the auto-off feature. The indicators are quite clear and legible. Short press the button key to turn the backlight on and off.
Specification:
Pressure units: KPa, Bar, PSI, InHg, KgF/cm2
Temperature units: C, F
Test range: 0 KPa~6000 KPa
Resolution: 1KPa Accuracy: ±0.5T%
Overload: 10MPa
Operating temperature: -4F~140F/-20C~60C
Real-time vacuum pressure test and percentage
indication Automatic shutdown function: 10 minutes (switchable on/off, default on)
Main unit dimensions: 150x9Ox6Omm
