Description
Manufacturer: The M27C1001-10C1 chip is manufactured by STMicroelectronics, a leading semiconductor company.
Memory type: This is an EPROM (Erasable Programmable Read-Only Memory) memory, which means that it is a read-only memory that can be programmed and erased electronically.
Memory capacity: The capacity of this chip is 1 megabit, which is equivalent to 128 kilobytes of data storage.
Access Speed: The “10” in the chip name indicates that it has an access time of 100 nanoseconds (ns). This means that you can access the data stored in memory in a very short time.
Operating voltage: Typically, these chips operate on a supply voltage of 5 volts (V).
Package: The M27C1001-10C1 chip usually comes in a standard 32-pin package, such as the DIP (Dual In-line Package) package.
Programming and erasure functions: As an EPROM memory device, this chip can be electrically programmed by an ultraviolet (UV) writing process and erased by exposure to UV light.
Typical applications: This type of EPROM memory chip is commonly used in applications where data storage is required that does not need to be changed frequently, such as embedded systems, communication equipment, industrial control systems, among others.
The M27C1001-10C1 is a reliable and widely used EPROM memory chip in a variety of electronic applications that require non-volatile data storage.
Manufacturer: STMicroelectronics
Product Category: EPROM
RoHS: No
Mounting Style: SMD/SMT
Package/Box: PLCC-32
Type: OTP, UV
Memory size: 1 MB
Organization: 128 k x 8
Interface Type: Parallel
Operating Supply Current: 50 mA
Programming voltage: 12.75 V
Supply voltage – Max.: 5 V
Supply voltage – Minimum: 5 V
Minimum Operating Temperature: -40 C
Maximum operating temperature: +70 C
Series: M27C1001-10
Packing: Tube
Access time: 100 ns
Brand: STMicroelectronics
Moisture Sensitive: Yes
Access time to exit enablement: 50 ns
Subcategory: Memory and Data Storage
