Description
Upgraded version: Not only test antenna standing wave impedance, also can debug duplexer, filter insertion loss, isolation and test cable attenuation, shorten the coefficient, phase, amplification of antenna
amplifier 3GHz vector network analyzer, designed in collaboration with OwOComm. According to the LGPL license agreement, it is manufactured completely according to the v2_2 files issued by OwOComm in the Development Department, according to the original technical specifications, it uses a user interface similar to NanoVNA, but with a different technical architecture, SAA-2N/NanoVNA_V2.2 does not load the initial calibration data at startup and does not automatically interpolate the calibration data after the user changes the frequency, and you need to recalibrate or retrieve calibration data after each start and frequency change. Please read the user manual carefully before use to avoid damaging the device.
S21 transmission measurement: 70 dB (50 KHz-1.5 GHz), 60 dB (1.5 GHz-3 GHz). S11 Reflection Measurement: -50 dB (50 KHz-1.5 GHz), -40 dB (1.5 GHz-3 GHz); Antenna analyzer: 1.005 (50 KHz – 1.5 GHz), 1.02 (1.5 GHz-3 GHz); Flip Display, you can flip the screen for convenient
use NOTE: The new batch of SAA2N analyzers was updated with the laser labeling on the control panel, so you may find it difficult to read at first glance, the old labeling is easy to fade after long use, and we are working on that.
Frequency range: 50kHz – 3GHz
System dynamic range (calibrated) 70 dB (up to 1.5 GHz), 60 dB (up to 3 GHz)
S11 background noise (calibrated) -50 dB (up to 1.5 GHz), -40 dB (up to 3 GHz)
Sweep rate: 100 points/s
Screen 4 “” touch screen, 320 x 480 pixels
USB interface: Micro USB
Power: USB, 1A maximum charging current
Battery: 3000 mAh
lithium-ion Battery connector: JST-XH 2.54 mm
Maximum sweep points (on the device): 201
Maximum sweep points (USB): 1024
Return loss from port 2 (1.5 GHz): 20 dB type
Return loss from port 2 (3 GHz): 13 dB min.
Supported platforms for VNA-QT software: Linux, Windows (7+), Mac OS planned
