Description
The VEVOR portable digital oscilloscope with a sampling rate of 1 GS/s and a bandwidth of 100 MHz, is a versatile and effective instrument for measuring and analyzing electrical signals. Here are its main features, including the specifications of minimum and maximum voltages:
Main Features
Sampling Rate:
1 GS/s (Giga samples per second): High sampling rate that allows fast signals to be captured with great accuracy.
Bandwidth:
100 MHz: Suitable for most signal measurement and analysis applications in educational, industrial, and research environments.
Number of Channels:
Four Channels: Allows simultaneous visualization and comparison of up to four different signals, which is useful for complex circuit analysis.
Screen:
LCD Display: Provides a clear and detailed display of waveforms and measured data.
Voltage Specifications
Maximum Input Voltage:
Safety Category: According to the user manual and technical specifications, the maximum input voltage is usually specified in terms of peaks or RMS (Middle Square Root).
Maximum Peak-to-Peak (Vp-p): The maximum input voltage can be around 400 Vp-p (peak to peak volts), depending on the exact model and probe configuration.
RMS (for CAT II safety category or similar): This can be around 300V RMS, but it is important to check the exact specifications and safety categories in the manual.
Minimum Input Voltage:
Sensitivity: Modern oscilloscopes have high sensitivity, which can be as low as a few millivolts per division. This allows very small signals to be measured.
Voltage Range: They can often measure anywhere from a few millivolts (mV) to hundreds of volts.
Common Education Applications
:
Labs: Used in educational labs to teach students about signal analysis and electronics.
Maintenance and Repair:
Circuit Diagnostics: Helps in the identification and repair of problems in electronic circuits.
Research and Development:
Prototyping and Testing: Essential in the development and testing of new devices and circuits.
Industrial Applications:
Quality Control: Used to verify the quality and performance of electronic products.
Benefits of the VEVOR Digital
Oscilloscope Portability: Its compact and portable design allows its use in different environments and facilitates transport.
Multifunctionality: With four channels, it allows for detailed and comparative analysis of multiple signals.
High Speed and Accuracy: The 1 GS/s sampling rate and 100 MHz bandwidth ensure accurate capture of fast signals.
Intuitive Interface: The LCD screen and easy-to-use controls make it accessible for both beginners and experienced professionals.
In summary, the VEVOR portable digital oscilloscope with specifications of 1 GS/s sampling rate and 100 MHz bandwidth is a powerful and versatile tool for electrical signal analysis. With the ability to handle a wide range of voltages and applications, it is suitable for educational use, maintenance, research and development, as well as industrial applications.
Product
Features Number of Channels: 4 channels
Oscilloscope Type: Digital
Oscilloscope Display: LCD
Display Communication: SCPI and LabVIEW
Support Sampling Rate: 1GS/s
Maximum Bandwidth: 100 MHz
Analog Bandwidth: 100 MHz
Number of Waveforms: Stores up to 16 waveforms
Waveform Mathematics: +, -, *, /, FFT
Maximum Input Voltage: 400Vpp
Dimensions & Weight
Product Dimensions: 1.85 x 5.98 x 2.76 inches / 301 x 152 x 70 mm
Product Weight: 3.42 lbs / 1.55 kg
Maximum Log
Length Maximum Log Length: 20K
