Description
The HT5910 is an advanced digital resistance meter with a 4.7-inch LCD screen, designed for various electrical measurement applications. Its main features are detailed below:
Key features:
Display:
4.7-inch LCD with backlight for easy reading in low light conditions.
Measurement Functions:
Resistance: Capable of measuring up to 1000 megohmmimmeters.
RCD/Loop Leak Meter: Designed to measure insulation resistance and detect electrical leaks.
Voltmeter: To measure voltages accurately.
Applications:
Ideal for technicians and electricians who need to measure insulation resistance, current leakage, and voltage in electrical systems.
Used in maintenance of electrical installations, testing of differential protection devices (RCD) and in the detection of insulation problems in cables and equipment.
Other Features:
Backlight: Makes it easy to read the values in low-light environments.
Ergonomic Design: Robust and durable construction, suitable for field use and adverse conditions.
The HT5910 is an essential tool for professionals in the electrical field, providing accurate and reliable measurements with a clear and easy-to-use user interface.
/> Multifunctional for measuring trip current, trip time, circuit breaker leakage loop resistance and voltage, on-line voltage frequency, RCD (ground fault interrupter), AUTORAMP (activated current).
Functional characteristics of measuring jump current, jump time, touch voltage, loop resistance.
Up to 1000 sets of test results can be saved, convenient for further reference.
Data stored on the host can be uploaded to a PC via the USB 2.0 interface.
The compact portable resistance tester is easy to operate and has stable performance.
4.7-inch backlit LCD screen to conveniently check the test result in low-light conditions.
Powered by 6 1.5 V AA batteries (not included), with low battery indicator.
Perfect for electricians to test, check and repair.
Specifications:
Material: ABS.
AC phase: voltage measurement: 0~440 V.
Frequency measurement: DC, 45~65Hz.
Test current increase: 0.5, 1 and 5
Fast/slow current testers: 10, 30, 100, 300, 500 mA
Safety level: CAT III 1000 V, CAT IV 600.
Max. Common mode voltage: 600 V AC RMS.
Screen type: LCD screen.
Selection range: fully automatic
range Frequency detection: Automatic
Superarea display: “>”
Power consumption: 100 mW.
Operating temperature and head: 0~4°C, 2000m
Storage temperature and height: -20~70°C, 12000m.
Power supply: 8 x 1.5 V AA batteries (NOT INCLUDED).
Item size: 190 x 140 x 68 mm / 7.48 x 5.51 x 2.68 inches.
Item weight: 948 g.
Package weight: 1544 g.
Package size: 33.5 x 27 x 9 cm.
